Maximum planing length: 1000mm
Working surface size on the workbench: 1000×500mm
Technical Parameters:
| project | Specifications |
| Machine model | BK60100 |
| 1. Maximum planing length | 1000mm |
| 2. Ram working stroke speed (stepless) | 3-38m/min |
| 3. The maximum distance from the bottom surface of the ram to the working table | 400mm |
| 4. Maximum cutting force | 28kN |
| 5. Maximum stroke of the tool holder (CNC servo). | 160mm |
| 6. The size of the working surface on the workbench (length × width) | 1000×500mm |
| 7. The width of the T-groove on the working surface of the workbench | 22mm |
| 8. The maximum transverse stroke of the worktable | 1200mm |
| 9. The horizontal feed range of the worktable for each reciprocating stroke of the ram (stepless) | CNC servo stepless control |
| 10. The maximum bearing mass of the workbench | 600kg |
| 11. a main motor | 7.5kw |
| 12. The workbench moves the motor quickly | 0.75kw |
| 13. Dimensions (length× width× height) | 4340*2150*2050 |
| 14. Net weight (approx.) | 4980kg |
| 15. Surface roughness | 3.2 |
Product description:
The ram carries the planer knife for horizontal linear movement. The turret can be rotated at an angle in the vertical plane and can be fed manually. The workbench carries the workpiece for intermittent horizontal or vertical feed movements, machining planes and grooves. Grooves and dovetail surfaces can also be used to machine formed surfaces, such as turbine blades. Rams and slides can also be moved on the bed (horizontal) or column (vertical) and are suitable for planing the local plane of very large workpieces. The workpiece that has been fixed on the machine table is cut with a tool in reverse motion.
Product features:
The machine has advanced design, beautiful appearance, reliable performance, stable precision, simple operation and convenient maintenance.
